    Rotary drilling tools drilling bucket Core Barrel with Bullet teeth

    Ask Lasest Price
    Brand Name : TUFF
    Model Number : 600-3000mm or as required
    Certification : ISO9001
    Price : $1,000.00 - $10,000.00/Unit
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 Unit/Units per Month
    Delivery Time : 3-5 days after payment
    • Product Details
    • Company Profile

    Rotary drilling tools drilling bucket Core Barrel with Bullet teeth

    Feature:
    Cutting ring with rock drilling bits and releases the internal stress of rock;
    Rock drilling bits perform stage breaking and drilling ;
    Small barrel facilitates the coring operation; large barrel performs stage breaking;
    Applicable layers: backfill layer,medium weathered rock, bedrock;


    Products Show:


    Cutting Dia.Shell HIT.Shell OD.Shell THK.Stiffening Ring THK.Stiffening Ring HIT.Teeth No.Weight
    φ600120052016202006520
    φ800120072016202009672
    φ9001200820162020010750
    φ10001200920162020011847
    φ1200120011201620200131010
    φ1500120014201620200161370
    φ1600120015201620200171493
    φ1800100017202020200191841
    φ200080019202020200211852
    φ220080021202020200232329
    φ250080024202020200272705
    φ280080027202020200303200
    φ300080029202020200323800
    Remark:all measurements in millimeters (mm); weight in kilograms(kg);

    Customizable Items:
    Cutting DIA. Custom : design various cutting diameter based on demand, like φ950,φ1050 etc.
    Shell HIT. Custom : design as demand, prolong or shortten, increase of efficiency by drilling more.
    Key Component Reinforce Custom : strengthen the key component to extend life cycle;
    Kelly Box Custom : custom kelly box size based on the kelly bar, like 130*130, 150*150,200*200 etc;
    Teeth No. Custom : encrypt the drilling teeth based on demand etc;
